CARB Certified | Yes |
---|---|
EPA Certified | Yes |
cETL Certified | Yes |
NOM Certified | Yes |
UL Certified | No |
Certification:
Model:
p03615
Generador portátil de gas de arranque remoto 4550/3650 vatios 30A 120/240V con certificación CARB y cETL con kit de ruedas
SERIES
Performance
TYPE
Open Frame Generator
P03628
FIRMAN LEGENDARY POWER
- 208cc engine
- Recoil start
- Electric start
- Remote start
- Low oil shut off
- Cast iron sleeve
- Running watts 3650W
- Starting watts 4550W
- 120 Volts

POWER WHERE YOU NEED IT
- 5-gallon steel tank
- Up to 14 hours of run time at 50% load
- Fuel gauge
- Weight: 101 lbs
- 67 dB ¼ load

ALL OF THE FEATURES YOU EXPECT FROM FIRMAN
3-year warranty
RV ready multi-feature control panel
- (1) 5-20R 120V 20A DUPLEX GFCI
- (1) TT-30R 120V 30A TWISTLOCK
- (1) L14-30R 120V/240V 30A TWISTLOCK (15.2A/240V/3650W)
- (1) 12V DC Power Port/Plug (8.3A/12V DC/100W)

Specifications
Certifications
Certifications
CARB Certified | Yes |
---|---|
EPA Certified | Yes |
cETL Certified | Yes |
NOM Certified | Yes |
UL Certified | No |
Output
Running Watts | 3650 |
---|---|
Starting Watts | 4550 |
AC Voltage | 120V / 240V |
Frequency (Hertz) | 60 |
Decibels | 75dB @ 3/4 load |
Run Time | 14 hours |
THD @ Full Load | 25% |
Output
Running Watts | 3650 |
---|---|
Starting Watts | 4550 |
AC Voltage | 120V / 240V |
Frequency (Hertz) | 60 |
Decibels | 75dB @ 3/4 load |
Run Time | 14 hours |
THD @ Full Load | 25% |
Control Panel
Recoil Start | Yes |
---|---|
Electric Start | Yes |
5-20R 120V 20A DUPLEX | 1 |
TT-30R 120V 30A RV | 1 |
L14-30R 120V/240V 30A TWISTLOCK (15.2A/240V/3650W) | 1 |
(1) 12V DC Power Port/Plug (8.3A/12V DC/100W) | 1 |
Control Panel
Recoil Start | Yes |
---|---|
Electric Start | Yes |
5-20R 120V 20A DUPLEX | 1 |
TT-30R 120V 30A RV | 1 |
L14-30R 120V/240V 30A TWISTLOCK (15.2A/240V/3650W) | 1 |
(1) 12V DC Power Port/Plug (8.3A/12V DC/100W) | 1 |
Machine
Low Oil Shutoff | No |
---|---|
Power Stream Alternator | |
Cast Iron Sleeve | Yes |
Machine
Low Oil Shutoff | No |
---|---|
Power Stream Alternator | |
Cast Iron Sleeve | Yes |
Fuel System
Fuel | Gas |
---|---|
Tank Size | 5 Gallons |
Steel/Plastic | Steel |
Fuel System
Fuel | Gas |
---|---|
Tank Size | 5 Gallons |
Steel/Plastic | Steel |
Wheel Kit
Wheels | 8.0" -black/yellow -plastic-flat free |
---|---|
Handle | single folding w/grip |
Wheel Kit
Wheels | 8.0" -black/yellow -plastic-flat free |
---|---|
Handle | single folding w/grip |
Packaging
Unit
UPC | 840876136157 |
---|---|
Unit Dimensions | 24.8x21.7x21.7 |
Unit Length | 24.8 |
Unit Width | 21.7 |
Unit Height | 21.7 |
Unit Weight | 119.5 |
Unit
UPC | 840876136157 |
---|---|
Unit Dimensions | 24.8x21.7x21.7 |
Unit Length | 24.8 |
Unit Width | 21.7 |
Unit Height | 21.7 |
Unit Weight | 119.5 |
Carton
Carton Dimensions | 27.2x19.1x20.5 |
---|---|
Carton Length | 27.2 |
Carton Width | 19.1 |
Carton Height | 20.5 |
Carton Weight | 132 |
Carton
Carton Dimensions | 27.2x19.1x20.5 |
---|---|
Carton Length | 27.2 |
Carton Width | 19.1 |
Carton Height | 20.5 |
Carton Weight | 132 |
