Certification: Certification cETL Certification EPA
Model: p03603

4550/3650 Watt
Remote Start Gas Portable Generator cETL Certified With Wheel Kit

SERIES Performance
TYPE Open Frame Generator

Introducing the FIRMAN P03503 Generator – Safety meets Power! This powerhouse delivers 3550 watts at just 67dB, equipped with an advanced CO shutoff alert for your safety. It offers versatility with 30A plugs and RV readiness. Plus, it comes with a bonus cover, oil, funnel, manual, and wrench. Elevate your power game with the P03503 Generator!

Gas Portable Generator 4550W Remote Start with CO Alert

FIRMAN LEGENDARY POWER

  • 208cc engine
  • Recoil start
  • Electric start
  • Remote start
  • Low oil shut off
  • Cast iron sleeve
  • Running watts 3650W
  • Starting watts 4450W
  • 120 Volts

LEADING FUEL CAPACITY AND RUN TIME

  • 5-gallon steel tank
  • Up to 14 hours of run time at 50% load
  • Fuel gauge
  • Weight: 120 lbs
  • 67 dB ¼ load

ALL OF THE FEATURES YOU EXPECT FROM FIRMAN

3-year warranty

RV ready multi-feature control panel

  • (1) 5-20R 120V 20A DUPLEX
  • (1) L5-30R 120V 30A TWISTLOCK
  • (1) TT-30R 120V 30A TWISTLOCK

208CC

FIRMAN Engine

3650

Running Watts

4550

Starting Watts

5 Gallon Gas Tank

14 Hour Run Time

Specifications

Certifications
CARB Certified NO
EPA Certified YES
cETL Certified YES
NOM Certified YES
UL Certified NO
CARB Certified NO
EPA Certified YES
cETL Certified YES
NOM Certified YES
UL Certified NO
Output
Running Watts 3650
Starting Watts 4550
AC Voltage 120
Frequency (Hertz) 60
Decibels 67dB 1/2 load
Run Time 14hrs
THD @ Full Load 25%
Running Watts 3650
Starting Watts 4550
AC Voltage 120
Frequency (Hertz) 60
Decibels 67dB 1/2 load
Run Time 14hrs
THD @ Full Load 25%
Control Panel
Recoil Start YES
Electric Start YES
Remote Start YES
5-20R 120V 20A DUPLEX 1
L5-30R 120V 30A TWISTLOCK 1
TT-30R 120V 30A TWISTLOCK 1
Recoil Start YES
Electric Start YES
Remote Start YES
5-20R 120V 20A DUPLEX 1
L5-30R 120V 30A TWISTLOCK 1
TT-30R 120V 30A TWISTLOCK 1
Machine
Low Oil Shutoff YES
Power Stream Alternator YES
Cast Iron Sleeve YES
Low Oil Shutoff YES
Power Stream Alternator YES
Cast Iron Sleeve YES
Fuel System
Fuel Gas
Tank Size 5
Steel/Plastic STEEL
Fuel Gas
Tank Size 5
Steel/Plastic STEEL
Wheel Kit
Wheels 8.0" -black -plastic-flat free
Handle single folding w/grip
Wheels 8.0" -black -plastic-flat free
Handle single folding w/grip

Packaging

Unit
UPC 840876136034
Unit Dimensions 24.8x21.7x21.7
Unit Length 24.8
Unit Width 21.7
Unit Height 21.7
Unit Weight 119.5
UPC 840876136034
Unit Dimensions 24.8x21.7x21.7
Unit Length 24.8
Unit Width 21.7
Unit Height 21.7
Unit Weight 119.5
Carton
Carton Dimensions 27.2x18.5x19.9
Carton Length 27.2
Carton Width 18.5
Carton Height 19.9
Carton Weight 128
Carton Dimensions 27.2x18.5x19.9
Carton Length 27.2
Carton Width 18.5
Carton Height 19.9
Carton Weight 128

Manuals

P03603 Operators Manual

download

P03603 Quick Start / Stop Guide

download

P03603 Electrical Schematic

download
